Description
- Integrated integration: built-in 4K ultra-high-definition camera, microphone array, high-fidelity speaker, electric privacy cover and other functional modules
- Ultra-high-definition: using 8 million high-quality CMOS image sensor, it can capture 4K ultra-high-definition images, present clear and realistic ultra-high-definition video, vividly show the expressions and movements of people, and provide superb clarity and resolution image quality
- Distortion-free wide-angle lens: 115° ultra-wide-angle distortion-free lens, no need to adjust the lens position, all participants can be seen, easily covering every corner of the conference room
- Fully automatic privacy cover: automatically closed during non-video conferences to ensure privacy and security
- Microphone array: built-in 20-microphone array, real The voice tracking function tracks every speaker in real time, allowing remote participants to break the limitations of distance and experience an immersive, face-to-face experience
- Built-in speakers: Built-in dual 10W stereo high-quality dual speakers ensure that every participant can clearly hear the distant voice and provide a unique remote experience
- Audio processing: High-fidelity 48K audio sampling, lossless audio transmission, and advanced AEC with double-talk detection, together with AGC and ANS, ensure stable echo cancellation and natural 6-meter full-duplex high-quality callseven during simultaneous speech.
- Smart framing: Built-in face detection algorithm, automatically detects participants, and provides ideal framing
- Bluetooth 5.0: Can be connected to mobile phones or other devices via Bluetooth as a Bluetooth microphone and speaker
- Low noise and high signal-to-noise ratio: Low-noise CMOS and advancedAI2D/3D noise reduction deliver ultra-clear images with minimal noise. Voice Fencing adds an intelligent audio boundary that isolates in-room voices from outside noise, boosting audio SNR for focused, high-quality communication.
- Compatibility: compatible with Windows7, Windows10, Mac OS 10.10 or higher systems, suitable for mainstream cloud video platforms
Parameter
| Viewing angle | 115° (D) /106° (H) / 72° (V) |
| Aperture | F2.0 |
| Focal length | 1.89mm |
| Electronic zoom | 10X |
| Sensor | High-quality CMOS sensor, effective pixels 8 million, 16 : 9 |
| Minimum illumination | 0.5Lux |
| Digital noise reduction | AI 2D﹠3D digital noise reduction |
| Focus | Manual/Auto |
| Backlight compensation | On/Off |
| Exposure | Exposure parameters are adjustable, supporting automatic exposure |
| Video adjustment | Brightness, clarity, saturation, contrast, white balance, gain, anti-flicker, low brightness compensation and other parameters are adjustable |
| Signal-to-noise ratio | ≥50dB |
| Video format | HDMI: 4KP30, 1080P60 backward compatible; USB output: 4KP30, 1080P60 backward compatible |
| Video compression format | MJPEG, YUY2, H.264, H.265, NV12 |
| Privacy cover | Fully automatic lens cover, automatically closed when non-screen output, automatically opened when outputting screen |
| Number of microphones | 20 MEMS microphones |
| Pickup distance | 6 meters |
| Frequency response | 120 Hz–16 kHz frequency response |
| Number of speakers | Built-in dual speakers |
| Power | 2*10W |
| Output sound pressure | ≥99db |
| Frequency response | 100 Hz-20 KHz frequency response |
| Audio processing | AEC, AGC, ANS |
| Group frame selection | Automatically adjust the screen size according to the number of participants and changes in position to present the best framing |
| Speaker tracking | Supports voice tracking function, real-time tracking of each speaker, ensuring that the speaker is in the center of the screen in real time |
| Remote control | Infrared remote control |
| USB | USB3.0 audio and video output interface, C port |
| HDMI interface | HDMI video output interface |
| LINE IN | 3.5mm audio linear input interface (when an external pickup is connected, the audio input automatically switches to the external pickup) |
| LINE OUT | 3.5mm Linear output, external speaker can be connected (when external speaker is connected, audio output automatically switches to external speaker) |
| Extension microphone interface | RJ45 expansion microphone interface, can connect expansion microphone |
| Power interface | HEC3800 power socket (DC12V), input AC110V-AC220V output DC12V/2A |
| Bluetooth 5.0 | can be connected to mobile phone or other devices via Bluetooth as Bluetooth microphone and speaker |
| Supported operating system | Windows 7, Windows 8, Windows 10, Mac OS X, Linux, Android |
| Storage temperature | -10℃～+70℃ |
| Storage humidity | 20%～95% |
| Working temperature | -10℃～+50℃ |
| Working humidity | 20%～80% |
| Wall mounting | support wall mounting |
| Desktop mounting | comes with desktop mounting bracket |
| Display screen installation | optional display screen upper/lower mounting bracket |
