Preamplifier FP4-C68058

- The mixer features 5 MIC inputs, 3 AUX line inputs, and 2 emergency EMC inputs with priority controls. - MIC5 has top priority and forced cut-in, while EMC inputs offer secondary priority. - Independent volume control, treble, and bass adjustments for optimal sound quality.
Categories:
Get Quote
Category Tags , , , ,
Description
  • 5 microphone (MIC) inputs, 3 standard line (AUX) inputs, and 2 emergency line (EMC) inputs
  • The fifth microphone (MIC5) has both top priority and forced cut-in priority. The top priority of MIC1 and EMC can be toggled on and off via a pull-out switch, allowing users to select the preferred setting based on their needs
  • The four emergency inputs have a secondary priority level and forced cut-in priority
  • MIC1, 2, 3, 4, 5, and the two emergency (EMC) inputs each feature an auxiliary line input
  • MIC1, 2, 3, 4, and AUX1, 2, and 3 can be cross-mixed
  • Both the MIC and line (AUX) inputs have independent volume control, including a master volume knob
  • Independent treble and bass adjustments
    • Parameter
    Input sensitivity for microphones 1-55mV/600Ω unbalanced for microphones; 775mV for line RCA inputs. /10KΩ unbalanced
    Auxiliary Inputs 1-3AUX 1, 2, and 3: 3500mV/10KΩ unbalanced
    EMC Inputs 1-2RAC: Unbalanced 200mV-1000mV/10KΩ; MIC: Unbalanced 5mV-25mV/600Ω
    Frequency Response20Hz-20kHz (±3dB)
    Signal-to-Noise RatioMIC Input: 50dB; AUX Input: 80dB
    Tone AdjustmentBass: ±10dB at 100Hz; Treble: ±10dB at 10kHz
    Power Supply~220V/50Hz
    Power Consumption20W
    Donwload
    FP4-C68058
