Paperless Server FT-1800A

This paperless conference system rack server features a robust industrial-grade design with a standard 2U chassis, providing efficient data storage and management for conference software. It supports dual display outputs (HDMI and VGA), offers dual Gigabit networking, and is powered by a Zhaoxin KX-U6780A eight-core processor, ensuring excellent compatibility with various operating systems. The server also includes multiple I/O interfaces, making it versatile for data connectivity and expansion.
Categories:
Get Quote
Category Tags , , , ,
Description
  • Paperless conference system rack server, paperless conference system software data storage management center
  • Adopt industrial-grade industrial computer standard rack chassis design, standard 2U height
  • Adopt Magang high-grade flowerless galvanized plate design structure, with high anti-magnetic, dust-proof and impact-proof capabilities
  • Support synchronous dual display, one standard HDMI and one VGA signal output, support adaptive projection resolution, convenient for multi-adaptive screen display
  • Built-in dual Gigabit network card, realize internal and external network working at the same time
  • Two USB ports on the front panel, convenient for users to copy data and expand connected devices
  • Support Windows/Linux/Galaxy Kylin/UOS version and other operating systems, with excellent compatibility
  • Support 1 set of 3.5MM high-fidelity audio input and output interfaces (Line_ out, MIC_ in and Line_ IN)
  • The rear IO is equipped with 1 COM serial port, supporting RS232 mode
  • The front panel is equipped with power on and restart buttons, status indicator lights, which can intuitively check whether the device is running normally, and conveniently restart the device quickly
  • Support 1*M.2 2280PCLe, 1*3.5 hard disk slot
  • The core is the domestic Zhaoxin KX-U6780A eight-core processor, equipped with domestic BIOS, loaded with domestic operating system and domestic basic application software, to achieve independent control, safe and reliable domestic computer system platform
Parameter
ProcessorZhaoxin KX-U6780A, eight-core, 2.7GHz
Chipsetintegrated chipset N/A
Running memory16G, 2*U DIMM Slot, DDR4 2666
BIOSBYO BIOS, 64MbFlash ROM
Displayintegrated graphics card HDMI+VGA
Network interface2*RJ45 1000Mbps Gigabit network port
Hard disk capacity256G PCLe SSD (standard), support 1*M.2 2280 PCLe SSD, 1*3.5 hard disk slot expansion
I/O interface1*COM RS232, 2*LAN, 1*HDMI, 1*VGA, front 2*USB (2*USB2.0,), rear 6*USB (2*USB3.0, 4*USB2.0), 1*Line out, 1*Line in, 1*PS/2 keyboard interface
Working temperature0°C~60°C, storage temperature: -10°C~60°C, working humidity : 5%~95% relative humidity, no condensation
Power supplyATX300W power supply
ESDcontact 4Kv, air gap 6Kv strong electromagnetic interference
Box materialMagang high-grade non-flowering galvanized plate
Installation methodrack installation
Operating systemdefault is Galaxy Kylin system, optional UOS/Windows/Linux
Vibration resistancein line with GB/T2423.10 standard
Expansion slot1*M2, 1*PCIEx16, 2*PCIEX1
Donwload
FT-1800A
