Pure power amplifier FT-B2846W

This amplifier features a 360W output, with constant voltage and resistance modes, and provides flexible connections via RCA and XLR jacks. It has robust protection features, including short circuit, overload, and temperature protection, along with a cooling fan. Ideal for professional audio applications, it ensures stable performance with low distortion and noise.
Categories:
Get Quote
Category Tags , , , ,
Description
  • Adopting a new pure copper transformer, it has stronger power and higher efficiency
  • Equipped with RCA jack and XLR jack, the interface is more flexible
  • Equipped with 100V, 70V constant voltage output and 4~16Ω constant resistance output
  • The output volume is adjustable
  • 5-unit LED display, easy to observe the working status
  • With perfect output short circuit, high temperature, overload, DC protection function
  • Cooling fan temperature control start
  • Rated output power:460W
  • Output mode:4-16 ohms(Ω) constant resistance output 70V(10.7 ohms(Ω))100V(21.7 ohms(Ω)) constant voltage output
  • Line input:10k ohms(Ω)< 1V, unbalanced
  • Line output:10k ohms(Ω) 0.775V (0 dB), unbalanced
  • Frequency response:60 Hz ~ 15k Hz (±3dB.
Parameter
Non-linear distortion THD<0.5% at 1kHz, 1/3 rated output power
Signal-to-noise ratio S/N>70 dB
Damping coefficient200
Voltage rise rate15V/uS
Output regulation rate< 3 dB, from no-signal static working state to full-load working state
Function controlone volume adjustment, one power switch
Cooling methodDC 12V FAN forced air cooling method
Indicator lightpower:‘POWER’, top elimination:‘CLIP’, signal:‘SINGNAL’, protection:‘PROT’, high temperature:‘TEMP’
ProtectionAC FUSE×12A AC FUSE×1, load short circuit, over temperature
Power cord(3×1.5 mm2)×1.5M (standard)
Power supplyAC 220V ±10% 50-60Hz
Power consumption620W
Machine size89(H)×483(W)×366(D)mm
Net weight17.66kg
Donwload
FT-B2846W
