| Display Specifications |
| Specification | Details |
| Size | 98 inches |
| Dimensions (Bare Machine) | 2216.8 x 99.3 x 1314.8 mm |
| Packaging Dimensions | 2443 x 260 x 1518 mm |
| Display Area | 2160.5 mm (H) × 1217.3 mm (V) |
| Pixel Pitch | 0.5622 mm x 0.5622 mm |
| Best Resolution | 3840 (H) × 2160 (V) (UHD) |
| Brightness | 400 cd/㎡ |
| Contrast Ratio | 1200:1 (Typ.) |
| Viewing Angle | 178° Horizontal, 178° Vertical |
| Response Time | 8 ms |
| Display Colors | 10 bit / 1.07 Billion |
| Backlight Type | DLED |
| Screen Lifespan | ≥50,000 hours |
| Speakers | 2 x 8Ω 10W |
| Power Consumption | ≤516W |
| Operating Voltage | 100V-240VAC, 50/60Hz |
| Net Weight/Gross Weight | 93 kg / 115 kg ± 5 kg |
| Touch Specifications |
| Specification | Details |
| Touch Integration | Built-in, integrated design (non-external) |
| Writing Methods | Finger, touch pen, or any non-transparent object with a diameter ≥ 5 mm |
| Touch Points | 20 points |
| Touch Accuracy | ±2mm |
| Response Speed | ≤12 ms |
| Touch Resolution | 32768 x 32768 |
| Touch Life Cycle | Theoretical unlimited touches |
| Transmission Speed | 12 Mbps, 115200 bps |
| Scan Frequency | >100 Hz/S |
| Interface Type | A-type USB male + UART |
| Driver | System auto-recognition, no driver required |
| Supported OS | Windows 7/10, Android, Mac OS, Linux |
| Operating Voltage | 4.75V ~ 5.25V |
| Operating Current | ≤400mA |
| Operating Temperature | -10℃ ~ 50℃ |
| Android Mainboard Specifications |
| Specification | Details |
| Board Model | MSD848 (8386) |
| CPU | Cortex A73 x2 + A53 x2, 1.5 GHz |
| RAM | 3 GB |
| Memory | 32 GB |
| System Version | Android 8.0 |
| Front Ports | 2 x USB 2.0 |
| Rear Ports | 2 x HDMI, 1 x HDMI OUT (optional), 2 x USB 2.0, 1 x AV IN, 2 x RJ45, 1 x VGA IN, 1 x VGA Audio, 1 x RS232, 1 x RF, 1 x SPDIF OUT, 1 x Earphone, 1 x Touch USB-B, 1 x YPbPr IN |
| Audio Formats Supported | MPEG1/2 layer I/II, AAC-Lc, WMA, etc. |
| Video Formats Supported | MPEG-2/4, AVS, H.264, H.265, TS, Realmedia, etc. |
| Image Formats Supported | JPG, BMP, PNG, etc. |
