Description
- New zero-bonding technology, low parallax writing and wider viewing angles.
- l3mm anti-glare tempered glass.
- lSupport brightness adjustment based on ambient light and DC dimming (to reduce screen flicker), providing a more eye-friendly display.
- l4K Ultra HD display, support for full-channel 4K UI display.
- l2 front USB 3.0 ports + 2 onboard USB 3.0 ports, supporting switching with channels.
- l2 onboard full-featured Type-C ports (15W) *1; 1 front Type-C port supporting PD 65W (switches to 15W when OPS is inserted).
- lSupport screen mirroring.
- l±1mm high precision IR touch makes the user write more smoothly.
- lSupport dual pens with different color displays, which makes teamwork easier.
- lSupport Wi-Fi6，dual-band 2.4G/5G, and AP+STA operation mode.
- lIntelligent wake-up for HDMI/VGA/RS232 channels & network signal input in standby mode.
- lSupport one wired network, both Android and OPS system are 1000Mbps networks.
- lSupport network sharing.
- lHigh-level welcome application, enriching the live interactive experience with great fun.
- lSplit whiteboard, parallel tasks and wider scenes.
Parameter
| 1. Display | |
| Size | 65” |
| Response Time | 8 ms |
| Aspect Ratio | 16:09 |
| Display Area | 1428.48（H）×803.52 （V）mm |
| Resolution | 3840（H）×2160（V） |
| Pixel Pitch | 0.372×0.372mm |
| Refreshing Frequency | 60Hz |
| Display Color | 1.07B (10bit) |
| NTSC | 72% |
| Contrast Ratio | 1100:1/1200:1/1300:1/5000:1 |
| Viewing Angle | 178°(H/V) |
| Back Light Unit | DLED |
| Brightness(typ) | 350cd/m2 |
| Life Time | ≥30000hrs |
| 2. Audio | |
| Sound Channel | 2 |
| Speaker Power | 2×16W |
| 3. Camera | |
| Pixel | 50MP |
| Quantity | 1 |
| Location | Upper frame |
| Function | Supports sound source localization, Autoframing, 4K photography, camera image super-resolution, and multimodal recognition. |
| 4. Microphone | |
| Distance of a Pickup | 0~8m |
| Quantity | 8 |
| Pickup Angle | 0°~180° |
| Function | Support intelligent noise reduction, gain control, echo cancellation, reverberation suppression |
| 5. Touch System | |
| Sensing Type | IR Touch |
| Supported System | Windows10/Windows8/Windows7/Windows XP/Android/Linux/Mac OS X/Chrome |
| Touch Point | 10-point writing, 50-point touch (Android 32 points, Windows 50 points) |
| EDLA: Android 16-point touch | |
| Min. Object Size | 2mm |
| Touch Tool | Finger; passive IR pen |
| Response Time | ≤2.5ms |
| Accuracy | ±1mm |
| Writing Height | ≤1mm |
| Writing Display | Single stylus pen with two colors |
| Interpolation Resolution | 32767 (W) ×32767(D) |
| 6. Operating System | |
| Chip | RK3576 |
| System Version | Android 14.0 |
| Frequency | 2.2GHZ |
| CPU | A72*4+A53*4 |
| GPU | G52 MC3 |
| RAM | 8GB |
| ROM | 128GB |
| OSD | English, Simplified Chinese, Traditional Chinese |
| 7. Bluetooth | |
| Version | 5.2 |
| Operation Frequency | 2.4GHz |
| Operation Distance | 0~10m |
| Remark | Function achieved via wireless module SI07B |
| 8. Wi-Fi | |
| Version | 802.11ac/b/g/n/a/ax |
| Operation Frequency | 2.4GHz/5GHz |
| Operation Distance | 0~10m |
| Remark | Function achieved via wireless module SI07B |
| 9. Front Interface | |
| USB 3.0 | 2 |
| HDMI IN | 1 |
| touch USB | 1 |
| TYPE-C | 1 |
| Keys/light sensor/ remote control receiver | 1 |
| 10. Onboard Interface | |
| HDMI IN | 2 |
| HDMI OUT | 1 |
| DP | 1 |
| USB 3.0 | 2 |
| USB 2.0 | 1 |
| TOUCH USB | 1 |
| VGA IN | 1 |
| AUDIO IN | 1 |
| AUDIO OUT | 1 |
| RS232 | 1 |
| RJ45 IN | 1(speed: 10/100/1000Mbps) |
| RJ45 OUT | 1(speed: 10/100/1000Mbps) |
| SPDIF | 1 |
| TYPE-C | 1 |
| TF | 1 |
| 11. Power | |
| Power Requirements | 100-240V～ 50/60Hz 4A |
| Max Power | 400W |
| Standby Power | ≤0.5W |
| 12. Physical Specifications | |
| Dimension(L × W × T) | 1488.4×915.3×99.2mm |
| Dimension(package) | 1630×220×1050mm |
| L × T × H | |
| Thickness of Machine | 129.2mm（WIB9060G） |
| (including bracket) | |
| VESA | 600×400mm |
| Wall-hanging Screw Spec | M8×25mm |
| Net Weight | 32.95+/-1Kg |
| Gross Weight | 42.95+/-1Kg |
| 13. Accessories | |
| Power Cord | ×1 |
| Stylus Pen | ×2 |
| Wall Mount | ×1 |
| Quick Start | ×1 |
| 14. Environmental Conditions | |
| Operation Temperature | 0℃~40℃ |
| Operation Humidity | 10%~90%RH |
| Storage Temperature | -20℃~60℃ |
| Storage Humidity | 10%~90%RH |
| Altitude | < 5000m |
| 15. Standard Module | |
| Wireless Module | SI07B（Wi-Fi 6.0） |
| 16. Optional Module | |
| OPS Module Dimension | OPS (120mm*180mm*30mm)European standard |
| (L × W × H) | |
