4-inch programmable touch screen T2-PLA104

This wall-mounted programmable touch control screen supports RS-485 communication, customizable interfaces, and multiple image formats. It operates on an ARM Cortex-A7 dual-core CPU with an 800x280 resolution IPS capacitive touch screen, and can function independently or with a central control system. It also allows for SD card writing, editable interfaces, and is designed for easy installation.
Categories:
Get Quote
Category Tags , , , ,
Description
FeatureDetails
Communication MethodRS-485
Expandable StorageSupports TF card expansion
Built-in FeaturesBuilt-in buzzer, Linux system
Baud RateAdjustable
ProgrammabilityFully customizable control interface
Image SupportSupports multiple formats (e.g., JPG, PNG)
Widget SupportCompatible with various control widgets
Page NavigationSupports swipe and button-based page flipping
SD Card SupportWritable via SD card
Interface EditingEditable user interface
Usage FlexibilityOperable independently or with a central control system
InstallationStandard 86-type wall mount
Parameter
ParameterDetails
Resolution800 × 280
CPUARM Cortex™-A7
ProcessorDual-core, 1.2GHz
ScreenIPS capacitive touch screen
Operating SystemNo operating system; operates immediately upon power-on
Storage16MB
Communication MethodRS-485
Firmware and Program UpdatesLocal updates via SD card
Power SupplyDC 12V, 1A
Device Dimensions174mm × 110mm × 43mm
Device Weight0.4kg
Donwload
T2-PLA104
