Professional LED controller DS-VP-K7

1U controller supports 5.2M pixels, 8 Ethernet outputs, and inputs via HDMI, SDI, 2× DVI. Max input resolution is 1920×1200@60Hz. Features cropping, splicing, scaling, 3-window display, audio input, HDCP, RS232 control, and wide operating temperature range.
Categories:
Get Quote
Category
Description
  • Supports a wide range of digital signal interfaces, including 2× DVI, 1× HDMI, and 1× SDI
  • Maximum input resolution up to 1920×1200@60Hz with customizable resolution settings
  • Video output load capacity: up to 5.2 million pixels, with a maximum width of 8192 pixels or height of 4096 pixels
  • Supports flexible video source switching, cropping, splicing, and scaling
  • Equipped with 8× Gigabit Ethernet outputs; supports single and dual-controller redundant backup
  • Supports up to 3-window display with freely adjustable size and position
  • Supports independent audio input
  • Brightness and color temperature adjustment supported
  • Supports low brightness with high grayscale performance, ensuring smooth gradation at low brightness levels
  • Compliant with HDCP high-bandwidth digital content protection protocol
  • Supports RS232 serial control protocol
Parameter
CategorySpecification
Input Interfaces- 1× SDI input, supports 1080P, 1080i, 720P, compliant with 3G-SDI standard
- 1× HDMI input, supports EIA/CEA-861 standard (up to 1920×1200@60Hz), HDCP 1.4 supported, 8-bit RGB444 / YCbCr444 / YCbCr422
- 2× DVI inputs, VESA standard (up to 1920×1200@60Hz), HDCP 1.4 supported, 8-bit RGB444 / YCbCr444 / YCbCr422
- 1× Audio input, transmitted via network cable to multifunction card
Output Interfaces8× 1Gbps RJ45 ports, support flexible up/down/left/right splicing
Control Interfaces- 1× USB OUT for controller cascade
- 1× USB IN for PC debugging
- 1× RJ11 (6P6C) port for central control system
Chassis Size1U standard rack-mountable chassis
Input VoltageAC 100~240V (wide voltage range)
Power ConsumptionRated: 25W
Operating EnvironmentTemperature: -20℃ to +70℃
Humidity: 0%–80% RH, non-condensing
Storage EnvironmentTemperature: -30℃ to +80℃
Humidity: 0%–90% RH, non-condensing
Net Weight2.3 kg
