| LED Module Parameters | |
| Item | Specification |
| LED Type | SMD 1010 |
| Scanning Method | 1/64 Scan |
| Pixel Pitch | 1.25 mm |
| Pixel Configuration | 1R1G1B |
| Pixel Density | 640,000 pixels/㎡ |
| Module Resolution | 256 (W) × 128 (H) |
| Module Size | 320 mm × 160 mm |
| Main Performance Parameters | |
| Item | Specification |
| Minimum Viewing Distance | ≥ 1.25 m |
| Horizontal Viewing Angle | ≥ 170° |
| Vertical Viewing Angle | ≥ 170° |
| Color Temperature | Adjustable from 1000K to 10000K |
| Screen Flatness | ≤ 0.2 mm |
| Single Point Calibration | Brightness and chroma calibration |
| Brightness Uniformity | ≥ 99% |
| White Balance Brightness | ≥ 580 cd/㎡ |
| Drive Protection & High Grayscale / High Refresh | Supported |
| Contrast Ratio | ≥ 10,000:1 |
| Refresh Rate | ≥ 3840 Hz |
| Frame Rate | ≥ 60 Hz |
| Grayscale Level | 65,536 levels |
| Driving Mode | Constant Current |
| Control System | Synchronous |
| Control Distance | Ethernet: 100 m / Fiber: 10 km |
| Signal Interface | RJ45 |
| Brightness Adjustment Range | 0–100% stepless adjustment |
| Continuous Working Time | ≥ 72 hours |
| Typical Lifespan | 100,000 hours |
| Protection Rating | IP5X |
| Cabinet Installation | Magnetic front service |
| Electrical Parameters | |
| Item | Specification |
| Operating Voltage | DC 4.2–5V |
| Power Supply Requirements | AC 220V ±10%, 50Hz ±5% |
| Max Power Consumption | ≤ 650 W/㎡ |
| Average Power Consumption | ≤ 228 W/㎡ |
| Environmental Parameters | |
| Item | Specification |
| Storage Temperature Range | -20°C to +60°C |
| Operating Temperature Range | -20°C to +50°C |
| Operating Humidity Range | 10%–80% RH (non-condensing) |
