Description
- Supports 7×24 hours of continuous operation
- Supports horizontal and vertical installation
- Supports RS232 daisy-chain connection and remote control
- Supports custom full-screen image display when there is no signal
- When a signal is input, the signal source is intelligently recognized, and the device automatically switches to the corresponding channel without manual adjustment
- Supports Intel OPS module PC, enabling audio, video, and data communication via HDMI, USB, etc.
Parameter
| Panel | |
| Item | Specification |
| LCD Size | 65" |
| Panel Grade | Grade A |
| Backlight | LED |
| Resolution | 3840 x 2160 pixels (4K UHD) |
| Brightness | 350 cd/m² (typ.) |
| Contrast Ratio | 1100:1, 1200:1, 4000:1, 5000:1 (typ.) |
| Pixel Pitch | 0.372 (W) x 0.372 (H) mm |
| Refresh Rate | 60 Hz |
| Viewing Angle | 178° (H) / 178° (V) |
| Lifetime | ≥ 50,000 hrs |
| Color Saturation | 70% |
| Viewable Area | 1432.28 (H) mm × 808.41 (V) mm |
| Color Depth | 1.07 Billion (8-bit + Hi-FRC) |
| Chipset | MSD3683 |
| Power | |
| Item | Specification |
| Voltage | Rated: 100-240V~; Max: 90-264V~; 50/60Hz |
| Max Power Consumption | ≤180W |
| Standby Power | ＜0.5W |
| Built-in Speaker | 2 × 10W (Max) |
| Power Input | AC 100–240V |
| Power Switch | Rocker Switch |
| Environment | |
| Item | Specification |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Operating Humidity | 10% – 90%, non-condensing |
| Input Interfaces | |
| Interface | Qty |
| HDMI IN | 1 |
| VGA IN | 1 |
| AUDIO IN | 1 |
| CVBS IN | 1 |
| DVI IN | 1 |
| USB 2.0 | 1 |
| RS232 | 1 |
| OPS Slot (80PIN JAE) | 1 |
| Output Interfaces | |
| Interface | Qty |
| Earphone OUT | 1 |
| RS232 OUT | 1 |
| OPS Module (Optional) | |
| Interface | Qty |
| USB | USB 2.0 × 2; USB 3.0 × 2 |
| LAN | 1 |
| HDMI OUT | 1 |
| LINE OUT | 1 |
| MIC IN | 1 |
| Mechanical | |
| Item | Specification |
| Net Weight | 24 ± 1 kg |
| Gross Weight | 32.8 ± 1 kg |
| Dimensions (W×H×D) | 1446.08 × 822.21 × 65 mm |
| Package Dimensions | 1630 × 220 × 1050 mm |
| Material | Aluminum frame + Sheet metal back |
| Color | Front: Black / Rear: Black |
| Bezel Width (T/B/L/R) | 26.8 / 27.8 / 26.8 / 26.8 mm |
| VESA Mount | 500 × 400 mm |
| OSD Language | Chinese, English, etc. |
| Accessories | |
| Item | Qty |
| Remote Control | 1 |
| Power Cable (1.5M) | 1 |
| User Manual | 1 |
| Quick Start Guide (A5 Folded) | 1 |
| Battery | 1 |
| Wall Mount Bracket | 1 |
