| Rated power (THD = 1%, continuous sine 1kHz, typical value) | 8Ω/stereo: 2×1000W、4Ω/stereo: 2×1700W、2Ω/stereo: 2×2890W |
| Rated power (THD = 1%, continuous sine 1kHz, typical value) | 16Ω/bridge: 1×2000W、8Ω/bridge: 1×3400W、4Ω/bridge: 1×5780W |
| RMS output voltage (THD = 1%, 1kHz) | 89.4V |
| Input sensitivity (rated output power, 1kHz) | Optional： 38dB, 35dB, 32dB, 29dB |
| THD+N | typical value：0.01% (10% rated output power, 1kHz, 8Ω) |
| Crosstalk suppression | ≥90dB (lower than rated power, 20Hz-1kHz, 8 Ω) |
| Frequency response | Typical value：+0dB, -0.5dB (10% rated output power, 20Hz-20kHz, 8Ω) |
| Input impedance | 20kΩ (balanced), 10kΩ (unbalanced) |
| Damping factor | Typical value：3500 (8Ω, 20Hz-200Hz) |
| Signal-to-noise ratio | ≥105dB (A-weighted, 20Hz-20kHz, 8Ω) |
| Power supply requirements | 90∽260VAC, 50/60Hz |
| Protection function | power supply undervoltage protection, amplifier output DC protection, overheating protection, temperature power control, overload power control |
| Dimensions (W×H×D) | 483×45×370 |
| Net weight | 9kg |
| Product static power consumption | 80 |
| Product dynamic power consumption | 427.2 |
