Description
Parameter
| Item | Specification |
| DMX512 Channels | 1024 |
| Max Number of Intelligent Fixtures | 96 |
| Fixture Address Reassignment | Supported |
| Fixture Pan/Tilt Swap | Supported |
| Fixture Channel Inversion | Supported |
| Fixture Channel Slope Mode Switching | Supported |
| Max Control Channels per Fixture | 40 main channels + 40 fine channels |
| Fixture Library | Supports Pearl R20 fixture library |
| Number of Storable Scenes | 60 |
| Number of Simultaneous Scenes | 10 |
| Total Steps in Multi-Step Scenes | 600 |
| Scene Time Control | Fade In, Fade Out, LTP Slope |
| Graphics per Scene | Up to 5 |
| Scene Activation and Dimming via Fader | Supported |
| Scene Interlock | Supported |
| Scene Trigger by Button | Supported |
| Built-in Shape Generator | Supports Dimmer, Pan/Tilt, RGB, CMY, Color, Gobo, Iris, and Focus effects |
| Simultaneous Running Shapes | 5 |
| Master Fader | Supported |
| Global Blackout / Replay / Instant Blackout | Supported |
| Channel Value Adjustment via Jog Wheel | Supported |
| Channel Value Adjustment via Fader | Supported |
| Fader Dimming | Supported |
| USB Support | FAT32 format |
| Dimensions | 480 × 420 × 130 mm |
